XR10 Picture Archive

[EEM-CrawlinMachine]

Stock Chassis

East End Machining Bent Rear & Straight Front Lowers
Stock Uppers
VP Lockouts
VP Incision Knuckles
VP Chubs
Punk DIG
Tekin FX-R Esc
Savox 1256TG Servo
2.2 Pitbulls
VP V1 Vented Wheels

Fin..



[MRCCRAWLER1.9]

Heres my BJv4 XR-10
CI links front and rear
VP transmission Case F/R
VP Plates F/R
parts list is still growing "thumbsup"

some pics:



[losiking1]

Here's a few finally

[/IMG][/IMG][/IMG]

Axial aluminum hubs,knuckles,lockouts,machined upper and lower links, CF chassis
Hitec 7950
Tekin FXR's and 35t motors
Futaba 4PK Super
Vanquish SLW V4 and HB Sedonas



[HARDKNOCKZ]

VANQUISH
*SLW VI
*DH PROCOMP II
*Knucks
*C-Hubs
*Lockouts
*Frt & rr motor plates
*Frt & rr Trans cases
*Frt & rr Link mounts
AXIAL
*XR10 Kit
*Machined gears all the way around
*Macined lower links
*30 degree bent pipe upper links
TEKIN
*Dual FXR's
HOLMES HOBBIES
*45T Torque Master Pro Handwounds
CC BEC
HITECH 7980TH Monster Torque servo 611 oz/in @ 7.4v
FUTABA 4PKS
Losi Boss Claws (2 sets...1 set cut & the other stock)
HB Sedonas

[/IMG]HARDKNOCKZ XR10



[RIG_RIDER]

I received an email from a friend with some pictures of his new XR10.

He's an intertard :lmao:, and asked me to post them.



[Rig Rocker]

The wife's first M.O.A. rig. Can you guess what chassis ????? :twisted:

BeetleJuice v4
XR10 Axles
Holmes Hobbies 45T Handwounds
V.P. Everything
Wht Rovers w/ Novas Foams
Dual FXR's
Futaba 4PL with Harley Setup "thumbsup"
Big Bores w/ Reds & Jeepindougs t-cups
Crawler Innovations Servo Guard
Rowdy Racing Batt Mount
BWD Lower links
4mm Revo / Jato everywhere
7955TG Servo
Castle Creations 10amp BEC

Here she is tearing up her first course with her new rig at the Beach



[irok22s]

Ok here is my xr:

Bjv4
VP Everything
axial gears
Nova foams
rovers, sedonas, or robras
Rowdy batt mount
bwd links
big bores w/cap mod
jeepindoug t-cups
Brood 2011 LE 35t doubles
7950 servo
dual brxl's
cc bec
4pl


Lets start it off with some big air :twisted:



[rcjackson0926]

rcjackson0926's Viper - Cajun Crawler


DSC_6956 by Quad Rider, on Flickr



[bogfrog]

Here's a few of mine:

Dual Tekin FXR's
Wantasummit proportional dig
HH torquemaster Pro 35T's
HS7950 Steering Servo
RC4WD gears
Spectrum SR3100 RX
DX3R TX
CC Bec
Vanquish DH 1 Wheels
Rover White Dots
Rowdy Racing Servo Armor and Battery Plate



[salty]

Here's my sled...

2X Tekin FXR esc's
Castle BEC@ 7.4V (servo warm but no probs. so far)
4PL tx, R2104 rx w/Harley's setup (thanks Harley!)
BJ-V4 chassis
VP wheels, weights, chubs, lockouts, knuckles, motor plates, gearcases
Boca gearcase bearings and HR gears (smooth like a baby's ass)
Lunsford 15T machined pinions
Venom Fireball 50T motors
Lunsford custom bent Ti lower links
HB Sedonas, nova foams front, proline foams rear
Savox 1256TG servo
Custom aluminum tie-rod (thanks RigRocker!)



[booher26]



[Bigpopa]

Well here is my basicly stock XR for now but we all know how that goes......Things get better with time................................:mrgreen:



[jkwrangler08]

Shouldn't orange crush have some Blue it it . Got the gears and plates it in yet??
Looks great. Can't wait to run with you in the future.



[dmcchaser]

Here's my new toy, a 30th birthday gift from my awesome wife.

I'm particularly happy with how the paint turned out. The pictures make it look white, but it's actually silver.
There's nothing quite like peeling the overspray mask off for the first time.

The outdoor shots were down at Long Beach WA. The rocks there were perfect for its first outing. This is also my first rig running Boss Claws, I'm pretty happy with them so far.

I spent quite a while arranging and re-arranging the components on the electronics tray to fit them in the smallest footprint. I was finally able to get them all to fit on the lower tray.

Overall I'm very happy with my XR10.



This is the first time I've uploaded pics, so I'm not quite sure what I'm doing, but it seems like it worked ok.



[vegas1973]



[lookeech]

my XR on local event.



[ev0l]

freshly built

VP C-hubs, Knuckles, lockouts, upper link mounts, Motor plates, Gearboxes, DH Pro-comps. RC4WD gear sets, Axial aluminum Upper links, Hitec HS7950TH servo, Tekin RS speedo, Punk Dig, Holmes Hobbies 540's, CC-BEC. Chaotic Crawlers Ti steering link, Axial aluminum shock caps and rings. Crawler Innovations Nova foams, Hot Bodies Rovers. Also now has losi gold springs. I think thats it..lol



[DonCrawla]

most vp upgrades
mt-4 radio
dual sidewinder esc
titanium hardware and lower links
dc tummy tuck on stock carbon fiber chassis
shaved and cut sedonas
dlux knuckle weights
traxas big boar shocks
mini t springs
RockThrasher paint and graphics paint job
parma body
hs80 hightech servo

i will have a build thread soon



[wyoming]

I won this neat XR10 kit as a raffle prize at MSD scale nats last week in Montana, thanks Axial. I typically just build scale trail rigs and I most likely won't ever be in a comp with this type of truck, so I went bone stock on this so I could get it up and running for as little $$ as possible using stuff I already had and just buying the M2 esc, some tires that were on sale and a box damaged Spektrum radio.

Totally Stock XR-10
Axial 55t Can motors
Novak M2 ESC
Hitec 5645MG Servo
Losi Comp claws (on sale buy one pair get one free at RPPhobby)
Venom 1600 mah NIMH 2/3a sized pack
Spektrum DX3E
Tamiya PS paints silver underocated with white then black then tinted windows and then used PS55 flat clear on outside over decals except windows for matte alloy look

Wow it worked really great and allowed me to actually play on some knarly parts of the very rocky landscape where I live instead of just driving around the bigger rocks to find more scale sized terrain for my typical rigs.

I built it in like 2 nights and its stock so no build thread was needed.



[grundic]

My XR Caterpillar...
