Formula Offroad Picture Archive

[click the pirate]

Here is my E Revo

Spools front and rear, Diff added to trans and Traxxas CVD's "thumbsup"



[ROLANDROCKSHOP]

DMG FOFF



[hatewater]

First test run of first foff

Check it out, see what you think. I didnt do a build thread, but I will get pictures posted once Its cleaned up and I have a body on it.


http://s276.photobucket.com/albums/...uper/?action=view&current=20110519_191330.mp4

Axial Axles with with 15mm widener
Vanquish Trans case
Robinson diff gear
32p 54t Delrin spur
Novak HV Esc W/ 4.5 turn Sensored brushless motor
78mm Integy Shock
Custom chassis and trays



[redrustbucket]

Mine.

Got Roost?



[Zarizi Tech]

Here's my garage at the moment:

Mercury - SC class

Pelkopopovicky - Modified class

Ramsessor - Modified class

Toxoplasma Condii - Modified class

Red Eagle - Unlimited class



[MR.VERTICAL]

Up hill drag racer.



[DustyfX4]

My FOFF and Scale Trucks!!!!!!!!!!



[jeepster73]

-bwd whiplash 13.5 chassis
-gunnar beef tubes f/r
-mip drive shafts
-vp Tranny housing/r&r gears and outdrive
-hd lockers/hd gears with front overdrive
-axial aluminum knuckles/c's/cvd's/rear straight's
-mayhem ''wicked j's'' 2.2 beadlocks
-panther shoes
-hitec 5955-tg servo
-mamba max pro esc
-cc (1406) 4 pole 4600kv brushless motor/3S
-proline powerstroke shocks



[rag6]

Posted pics in another forum, and was told it looks like a formula off road on steroids, so I'll post it here...

No build thread.
Ofna monster pirate mt wheels and tires
Blue and silver springs
Trx variable damping 55wt ft and r
Trx sways set soft as possible
100,000 wt diffs
18/65
Castle 1800kv 1512 1.5y with mmm
Spc lipo
Ebay body

Soon to come:
Summit axles
2 speed with 2ch link tx modded to 4ch w/lights
Rb innovations elec blower (just cause it looks so sweet!)
extended wb arms

This thing is super fun!



[conedog]

I haven't run this with the paddles yet, gonna test it out at an old sand mine down the street from my house once my 32P gears get here.



[mobias]

My FOFFing R1. Extended the front wheelbase a little and put axle wideners on. This thing will climb almost anything I've thrown at it, and creates a lot of mess doing so.

[/IMG]

[/IMG]

[/IMG]

[/IMG]



[MonstrsLV]

Here`s Mine
-Himoto EMXT-01 with brushless Team Orion Expierence 2800kv motor, HK 100A ESC and Turnigy 3s LIPO
-PROLINE Slingshots and JConcepts Rulux wheels



[Hoosierdady]

My HPI W/K, without a body at the moment.



[nut_up_racing]



[Slowbro]

Some cool pics of mine i took today



[skid]

A start



[nut_up_racing]

Made the switch to brushless/lipo... MaxAmps 3S on the way.

Here is my newest rig, Savage XS Flux. The 3S lipo/brushless setup should turn the paddles pretty good... "thumbsup"

Unboxed yesterday...

sandblasted the paint off the inside so the scratches will look grey after the paint scratches off the outside...

this "ruddy brown" primer should do the trick to make mine different...

after the paint dried, ready to rip, just waiting on my battery to get here...



[Hacksaw707]

mine;-)



[desertrat55]

Desertrat55's FOFF rig


Ax10 based "thumbsup"



[West Cork Basher]

Here's mine..

Axial AX-10 FOFFer.. - YouTube

Every thing you need to know is here..
Mad mAX-10..ProLine Tuber Cage Build.. - RCCrawler.com Bulletin Board


Sean
.
..
